FC_Vector3DEuclideanDistance - General Information
Overview
|
Type: |
Function |
|
Available as of: |
V1.0.0.0 |
|
Versions: |
Current version |
This chapter provides information on:
Description
Given two 3D input vectors, the function evaluates the Euclidean distance between the points described by such vectors.
Interface
|
Input |
Data type |
Description |
|---|---|---|
|
i_stVectorA |
SE_MATH.ST_Vector3D |
First 3D vector. |
|
i_stVectorB |
SE_MATH.ST_Vector3D |
Second 3D vector. |
|
Output |
Data type |
Description |
|---|---|---|
|
q_xError |
BOOL |
If this output is set to TRUE, an error has been detected. For details, refer to q_etResult and q_etResultMsg. |
|
q_etResult |
Provides diagnostic and status information. If q_xError = FALSE, then q_etResult provides status information. If q_xError = TRUE, then q_etResult provides diagnostic/error information. The enumeration ET_Result contains the possible values of the POU operation results. |
|
|
q_sResultMsg |
STRING[80] |
Provides additional information about the current status of the POU. |
